TRAXXAS - TRA820244 - TRX-4 Sport 1/10 Scale Trail Rock Crawler (Blue) w/XL-5 HV ESC & TQ 2.4GHz Radio

IN STORE PICKUP ONLY - WE DO NOT SHIP THIS ITEM

TRAXXAS - TRA820244 - TRX-4 Sport 1/10 Scale Trail Rock Crawler (Blue) w/XL-5 HV ESC & TQ 2.4GHz Radio

Features:

• Chassis:
  • Heavy-Duty Steel Frame Rails
  • Adjustable Wheelbase
  • Molded Wire Retainers
  • Dual Battery Tray
  • Floor Pans
  • Aluminum Scale Shocks
  • Heavy-Duty Steel Links
  • Precision Hex Hardware
• Driveline:
  • Portal Axles
  • Torque Twist Eliminated
  • Locked Differentials
  • Steel Gear Transmission
  • Hardened Steel U-Joints
  • Twin Friction Plate Slipper Clutch
  • Sealed Ball Bearings
• Geometry:
  • Raised Center Driveshafts and Suspension Links
  • High Steering and Drag Links
  • 45-Degree Steering Angle
  • Extreme Approach Angles
  • High Ground Clearance
  • Front Motor Design
• Electronics:
  • XL-5 HV ESC
  • Titan 21T 550 Motor
  • Waterproof Metal Gear Servo
  • TQ&trade 2-Channel Radio System

Specifications:
Length: 21.93 inches (557mm)
Front Track: 9.78 inches (249mm)
Rear Track: 9.78 inches (249mm)
Ground Clearance: 3.14 inches (80mm)
Weight: 5.79lb (2.63kg)
Height: 9.47 inches (241mm)
Wheelbase: 12.28 inches (312mm)
Approach Angle: 58.82°
Departure Angle: 45.83°
Breakover Angle: 58.93°
Front Shock Length: 3.54 inches (90mm)
Rear Shock Length: 3.54 inches (90mm)
Front Wheels: 1.9 x 1.02 inches (49 x 26mm)
Rear Wheels: 1.9 x 1.02 inches (49 x 26mm)
Front Tires: 4.64 x 1.89 inches (118 x 48mm)
Rear Tires: 4.64 x 1.89 inches (118 x 48mm)
Hex Size: 12mm
Speed Control: XL-5 HV
Motor (electric): 21T Reverse Rotation
Transmission: Single Speed
Gear Pitch: 32P
Differential Type: Spool (no differential)
Chassis Structure / Material: Steel Ladder Frame with Nylon Composite Crossmembers
Brake Type: Electronic “Hill Hold”
Drive System: Shaft Driven 4WD
Steering: Chassis Mounted Servo
Servo: 2075X Metal Gear
Transmitter: TQ&trade 2.4GHz 2-Channel Transmitter
Receiver: 6519
Skill Level: 2
Battery Tray: 158.75 L x 47 W x 23/26mm H

Needed To Complete:

• (4) "AA" Batteries (for transmitter)
• (1) NiMH Battery (4-7 cell) or LiPo Battery (2S/3S)
• (1) Compatible Battery Charger
